DentFix Tool
1 / 5
| Parameter | Details |
|---|---|
| Flutes No. | 2/3/4 Flutes |
| Material | HSS, Carbide etc. |
| Coating | AlTiN, NACO BLUE / NACO BLACK / TiN etc. |
| Helix Angle | 35°, 45° |
| Hardness | HRC45/55/58/65 |
| Size | Overall Length: 50-150mm |
| Customized | Accept |
| Smooth Finish | Highly Polished |
| Feature | Excellent chip evacuation |
| Measurement | Metric |
Material: WC=0.8(UM) Co=10 HRA=92.2 HV=1620 Rupture=4000(kg.N/mm²)
| Model Code | Diameter (mm) | Shank Dia (mm) | Flute Length (mm) | Overall Length |
|---|---|---|---|---|
| WEIX601 | 3 | 3 | 8 | 50L |
| WEIX602 | 1 | 4 | 3 | 50L |
| WEIX603 | 1.5 | 4 | 4 | 50L |
| WEIX604 | 3 | 4 | 5 | 50L |
| WEIX605 | 2.5 | 4 | 6 | 50L |
| WEIX606 | 3.5 | 4 | 10 | 50L |
| WEIX607 | 4 | 4 | 11 | 50L |
| WEIX608 | 5 | 5 | 13 | 50L |
| WEIX609 | 1 | 6 | 3 | 50L |
| WEIX610 | 1.5 | 6 | 4 | 50L |
| WEIX611 | 2 | 6 | 5 | 50L |
| WEIX612 | 2.5 | 6 | 6 | 50L |
| WEIX613 | 3 | 6 | 8 | 50L |
| WEIX614 | 3.5 | 6 | 10 | 50L |
| WEIX615 | 4 | 6 | 11 | 50L |
| WEIX616 | 5 | 6 | 13 | 50L |
| WEIX617 | 6 | 6 | 15 | 50L |
| WEIX618 | 7 | 8 | 17 | 60L |
| WEIX619 | 8 | 8 | 20 | 60L |
| WEIX620 | 10 | 10 | 25 | 75L |
| WEIX621 | 12 | 12 | 30 | 75L |
| WEIX622 | 14 | 14 | 35 | 100L |
| WEIX623 | 16 | 16 | 40 | 100L |
| WEIX624 | 18 | 18 | 40 | 100L |
| WEIX625 | 20 | 20 | 40 | 100L |
| Lengthening Series | ||||
| WEIX626 | 3 | 3 | 15 | 75L |
| WEIX627 | 4 | 4 | 20 | 75L |
| WEIX628 | 5 | 5 | 25 | 75L |
| WEIX629 | 6 | 6 | 25 | 75L |
| WEIX630 | 7 | 8 | 25 | 75L |
| WEIX631 | 8 | 8 | 30 | 75L |
| WEIX632 | 3 | 3 | 15 | 100L |
| WEIX633 | 4 | 4 | 25 | 100L |
| WEIX634 | 5 | 5 | 30 | 100L |
| WEIX635 | 6 | 6 | 30 | 100L |
| WEIX636 | 8 | 8 | 35 | 100L |
| WEIX637 | 10 | 10 | 40 | 100L |
| WEIX638 | 12 | 12 | 45 | 100L |
| WEIX639 | 8 | 8 | 40 | 150L |
| WEIX640 | 10 | 10 | 50 | 150L |
| WEIX641 | 12 | 12 | 50 | 150L |
| WEIX642 | 14 | 14 | 70 | 150L |
| WEIX643 | 16 | 16 | 70 | 150L |
| WEIX644 | 20 | 20 | 80 | 150L |
| HRC45 | HRC55 | HRC60 | HRC65 |
|---|---|---|---|
| YG10X | YG10.2 & WF25 (Taiwan) | K44 & K40 (German) | H10F (Sweden) |
|
Grain Size: 0.7um Co: 10% Flexural strength: 3320N/mm² |
Grain Size: 0.6um Co: 10% Flexural strength: 4000N/mm² |
Grain Size: 0.5um Co: 12% Flexural strength: 4300N/mm² |
Grain Size: 0.5um Co: 10% Flexural strength: 4300N/mm² |
We normally will dispatch your order within 2-10 working days depends on stock level. As soon as the order is shipped, we will list the tracking number on your order detail page. If there is any problem regarding the shipping, please feel free to contact us.
Orders ≤ $1000: 100% in advance via Paypal or Western Union.
Orders > $1000: 30% T/T deposit, balance before shipment.
